SFP-10G-SR-X
SFP-10G-SR-X
Multirate 10GBASE-SR, 10GBASE-SW and OTU2e SFP+ Module for MMF
SFP-10G-SR-X
GENERALES
Detalles del Módulo SFP-10G-SR-X
- Número de parte: SFP-10G-SR-X
- Descripción corta: Multirate 10GBASE-SR, 10GBASE-SW and OTU2e SFP+ Module for MMF, extended temperature range.
- Tipo dispositivo: SFP+ Transceiver Module
- Marca: Cisco Systems
ESPECIFICACIONES TÉCNICAS
Especificaciones Técnicas SFP-10G-SR-X
- Data Rate: 10 Gbps
- Form Factor: SFP+
- Reach: 400m
- Cable Type: Duplex Fiber
- Media: MMF
- Connector Type: LC (PC or UPC)
- Transceiver Type: Optic
- Case Temperature: -5 to 85C
- DOM Capable: Yes
- Standard: IEEE 10GBASE-SR
- Transceiver Notes: FDDI: 26m; OM1: 33m; OM2: 82m; OM3: 300m; OM4/OM5: 400m
Peso y Dimensiones
- Alto x Ancho x Profundidad: 8.5 x 13.4 x 56.5 mm
- Peso: 75 gramos
CISCO NETWORK SWICHES
Cisco network switches compatibles con SFP-10G-SR-X:
C9400, C9500, UCSB, CRS, NCS5000, NCS5500, NCS6000, C9300, ASR9000, ASR1000, ASR903, ASR901, ASR920, NCS4200.
Cisco network switches compatibles con SFP-10G-SR-X:
IE5000, C3850, C3650, NCS540, NCS560, C9600, C9300L, C9800, IE3300, NCS520, C8500, C9300X, ESS3000, C9300LM, IE9300.
MODELOS DE SWITCH CISCO
Modelo de Switch Cisco compatibles con SFP-10G-SR-X:
C9400-LC-24XY, C9400-LC-12QC, C9500-24Y4C, C9500-48Y4C, C9500-40X, C9500-NM-8X, C9500-16X, C9500X-28C8D, C9500X-60L4D, UCS-FI-M-6324, 40x10GE-WLO, NCS-5001, NCS-5002, NC55-MOD-A-S, NCS-55A2-MOD-S, NC55-MPA-12T-S, NC55-MOD-A-SE-S, NCS-55A2-MOD-HD-S, NCS-55A2-MOD-SE-S, NCS-55A2-MOD-HX-S, NCS-55A2-MOD-SE-H-S, NC55-32T16Q4H-A, NC57-MPA-12L-S, NC55-OIP-02, NCS-6008.
Modelo de Switch Cisco:
NC6-60X10GE-L-S, NC6-60X10GE-M-S, C9300-NM-2Y, C9300-NM-8X, ASR-9000V-AC, ASR-9000V-DC-A, ASR-9000V-DC-E, ASR-9000V-24-A, A9KV-V2-AC, A9KV-V2-DC-A, A9KV-V2-DC-E, A9K-24X10GE-SE, A9K-24X10GE-TR, A9K-36X10GE-SE, A9K-36X10GE-TR, A9K-MPA-8X10GE, A9K-24X10GE-1G-SE, A9K-24X10GE-1G-TR, A9K-48X10GE-1G-SE, A9K-48X10GE-1G-TR, A9K-MPA-20X10GE, A9K-400G-DWDM-TR, A99-48X10GE-1G-SE, A99-48X10GE-1G-TR, ASR-9901.
Modelo de Switch Cisco:
A9K-4HG-FLEX-TR, A9K-4HG-FLEX-SE, A99-4HG-FLEX-TR, A99-4HG-FLEX-SE, ASR-9902, A9903-8HG-PEC, ASR-9902-FC, A9K-4HG-FLEX-FC, A99-4HG-FLEX-FC, A9903-8HG-PEC-FC, A99-48X10GE-1G-FC, A9K-24X10GE-1G-FC, A9K-MPA-8X10GE-FC, A9K-MPA-20X10GE-FC, ASR-9901-FC, A9K-48X10GE-1G-FC, ASR1001-X, ASR1002-HX, ASR1001-HX, EPA-10X10GE, A900-IMA8S1Z, A900-IMA8T1Z, A900-IMA2Z, A901-6CZ-F-D, A901-6-CZ-FT-D.
Modelo de Switch Cisco:
A901-6CZ-F-A, A901-6-CZ-FT-A, ASR-920-10SZ, ASR-920-12CZ, ASR-920-12SZ-IM, ASR-920-24SZ-M, ASR-920-24SZ-IM, ASR-920-4SZ, ASR-920-24TZ-M, ASR-920-12SZ, ASR-920-20SZ-M, ASR-920-10SZ-PD, ASR-920-8S4Z-PD, NCS4200-1T8LR-PS, NCS4201-SA, NCS4202-SA, IE-5000-12S12P-10G, WS-C3850-48XS, WS-C3850-12XS, WS-C3850-24XS, C3850-NM-2-10G, C3850-NM-4-10G, C3850-NM-8-10G, WS-C3650-24PD, WS-C3650-24PDM.
Modelo de Switch Cisco:
WS-C3650-48PD, WS-C3650-48PQ, WS-C3650-48TQ, WS-C3650-8X24PD, WS-C3650-8X24UQ, WS-C3650-12X48UQ, WS-C3650-12X48UR, WS-C3650-48FQM, N540-24Z8Q2C-SYS, N540-ACC-SYS, N540X-ACC-SYS, N540X-16Z4G8Q2C-A, N540X-16Z4G8Q2C-D, N540-28Z4C-SYS-A, N540-28Z4C-SYS-D, N540X-12Z16G-SYS-A, N540X-12Z16G-SYS-D, N540-12Z20G-SYS-A, N540-12Z20G-SYS-D, N540X-8Z16G-SYS-A, N540X-8Z16G-SYS-D, N540X-6Z18G-SYS-A, N540X-6Z18G-SYS-D, N540-FH-CSR-SYS, N540X-4Z14G2Q-A.
Modelo de Switch Cisco:
N540X-4Z14G2Q-D, N540-24Q8L2DD-SYS, N540-FH-AGG-SYS, N540-6Z18G-SYS-A, N540-6Z18G-SYS-D, N540-6Z14S-SYS-D, N540X-16Z8Q2C-D, A900-IMA-8Z, A900-IMA-8CS1Z, N560-IMA-8Q/4L, C9600-LC-48YL, C9600-LC-40YL4CD, C9600X-LC-56YL4C, C9300L-24T-4X, C9300L-48T-4X, C9300L-24P-4X, C9300L-48P-4X, C9300L-24UXG-4X, C9300L-48UXG-4X, C9300L-48PF-4X, C9800-40-K9, C9800-L-F-K9, C9800-80-K9, C9800-10X10GE, IE-3300-8T2X-E.
Modelo de Switch Cisco:
N520-4G4Z, N520-X-4G4Z, N520-20G4Z, N520-X-20G4Z, C8500-12X4QC, C8500-12X, C8500L-8S4X, C9300X-12Y, C9300X-24Y, C9300X-NM-8Y, ESS-3300-NCP-E, ESS-3300-NCP-A, C9300LM-24U-4Y, C9300LM-48U-4Y, C9300LM-48UX-4Y, C9300LM-48T-4Y, IE-9320-22S2C4X-E, IE-9320-22S2C4X-A, IE-9320-24T4X-E, IE-9320-24T4X-A, IE-9320-24P4X-E, IE-9320-24P4X-A, IE-9320-16P8U4X-E, IE-9320-16P8U4X-A.
